Arduino
Arduino MKR1000
Arduino MKR1000
Regular price
$50 SGD
Regular price
Sale price
$50 SGD
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
Arduino MKR1000 is a powerful board that combines the functionality of the Zero and the Wi-Fi Shield. It is the ideal solution for makers wanting to design IoT projects with minimal previous experience in networking. Arduino MKR1000 has been designed to offer a practical and cost effective solution for makers seeking to add Wi-Fi connectivity to their projects with minimal previous experience in networking. It is based on the Atmel ATSAMW25 SoC (System on Chip), that is part of the SmartConnect family of Atmel Wireless devices, specifically designed for IoT projects and devices.
Specifications
| Microcontroller | SAMD21 Cortex-M0+ 32-bit low power ARM MCU (SAMD21G18A) |
| Wi-Fi | ATWINC1500 (part of the ATSAMW25 SoC) |
| Secure element | ATECC508A |
| Clock speed | 48 MHz (RTC 32.768 kHz) |
| Memory | 256KB Flash, 32KB SRAM |
| Digital I/O pins | 8 |
| PWM pins | 12 (0 - 8, 10, A3, A4) |
| Analog input pins | 7 (ADC 8/10/12 bit) |
| Analog output pins | 1 (DAC 10 bit) |
| External interrupts | 10 (0, 1, 4, 5, 6, 7, 8, 9, A1, A2) |
| Communication | UART, I2C, SPI |
| I/O voltage | 3.3V |
| Input voltage (nominal) | 5-5.5V |
| DC current per I/O pin | 7 mA |
| Supported battery | Li-Po single cell, 3.7V, 1024mAh minimum (JST PH connector) |
| USB connector | Micro USB |
| Dimensions | 61.5 mm x 25 mm |
| Weight | 32 g |
